GMWBZ5000GD-9D

Enhance your style with some seriously sophisticated timekeeping from the 5000 line. Directly descended from the first-ever G-SHOCK , the GMW-BZ5000 carries on the evolution of function and material in a transformative, unprecedented design.

Welcome to a new chapter in full-metal G-SHOCK watches. Tapping into shock-resistance data gathered over 40 years of G-SHOCK testing, we delved into co-creation between human designers and AI to find all-new methods of generative structural and exterior design.

We kept the iconic form of the original G-SHOCK, while developing a new structure that extends the case all the way to the lugs to even further mitigate shock transmission. The intricate, modern shape, seen from the side, highlights the design’s structural beauty. An internal protector made of resilient resin temporarily deforms to absorb shocks, achieving a timepiece with a full-metal exterior that meets G-SHOCK shock-resistance standards. The stainless-steel case employs a screw-lock case back to ensure a tight seal.

Additionally, to make solar-powered operation possible for the high-definition, full-dot MIP LCD with memory embedded in each pixel — a display commonly used in G-SHOCK sports models — we developed a more energy-efficient version. This new display offers a total of eight different display styles: you can choose from two distinct styles — the easy-read STANDARD and CLASSIC for a traditional 7-segment look — across four display modes. The display employs a high-precision, high-contrast MIP LCD with a wide viewing angle that not only charges from ambient light — sunlight or even fluorescent lamp light — but enables more detailed rendering for outstanding readability even in bright outdoor spaces and direct sunlight.

The time mode display layout carries on the look of the first-ever G-SHOCK, with traditional styling taking on advanced functionality. Download the CASIO WATCHES app to pair with your smartphone via Bluetooth®. With Multiband 6, Tough Solar charging system, and high-brightness LED light, you have complete practical utility at your fingertips.

This new chapter in G-SHOCK is crafted at Yamagata Casio, the “mother factory” where the original G-SHOCK story was written.

Case size (L× W× H)

49.3 × 43.6 × 13 mm

Weight

172 g

Case and bezel material

Stainless steel

Band

Solid stainless steel band
One-touch 3-fold Clasp

Construction

Shock Resistant

Water resistance

200-meter water resistance

Time adjustment

Radio-controlled Watch; Multi band 6
Bluetooth: Connects to a smartphone and automatically adjusts the time

Power supply and battery life

Tough Solar (Solar powered)


Smartphone Link feature

Mobile link (Wireless linking using Bluetooth®)

Apps

CASIO WATCHES

App connectivity feature

Auto time adjustment
Easy watch setting
Approximately 300 world time cities + user-added point
Time & place
Phone finder


Glass

Mineral Glass

Back plate

Screw Lock Back

Surface treatment

Black ion plated bezel
Black ion plated band

Compatible band size

150 to 205 mm


World time

2 World time 38 time zones (55 cities + coordinated universal time), city code display, city name display, daylight saving on/off, auto summer time (DST) switching, Home city/World time city swapping

Stopwatch

1/100-second stopwatch Measuring capacity: 00'00''00~59'59''99 (for the first 60 minutes) 1:00'00~23:59'59 (after 60 minutes) Measuring unit: 1/100 second (for the first 60 minutes) 1 second (after 60 minutes) Measuring modes: Elapsed time, split time, 1st-2nd place times

Timer

Countdown timer Measuring unit: 1 second Countdown range: 24 hours Countdown start time setting range: 1 second to 24 hours (1-second increments)

Alarm/hourly time signal

5 daily alarms (with 1 snooze alarm)
Hourly time signal

Light

LED backlight Full auto light, selectable illumination duration (1.5 seconds or 3 seconds), afterglow

Light color

LED:White

Calendar

Full auto-calendar (to year 2099)

Mute feature

Button operation tone on/off

Energy saving feature

Power Saving (display goes blank to save power when the watch is left in the dark)

Battery display/alert

Low battery alert

Run time

Approx. battery operating time: 6 months on rechargeable battery (operation period with normal use without exposure to light after charge) 22 months on rechargeable battery (operation period when stored in total darkness with the power save function on after full charge)

Accuracy

Accuracy: ±15 seconds per month (with no signal calibration and mobile link function)

Other features

12/24-hour format
Date/month display swapping
Regular timekeeping: Hour, minute, second, pm, month, date, day
Memory in Pixel (MIP) LCD

Time adjustment details

Time calibration signal reception Auto receive up to six* times a day (remaining auto receives canceled as soon as one is successful) *5 times a day for the Chinese calibration signal Manual receive The latest signal reception results
Time Calibration Signals Station name: DCF77 (Mainflingen, Germany) Frequency: 77.5 kHz Station name: MSF (Anthorn, England) Frequency: 60.0 kHz Station name: WWVB (Fort Collins, United States) Frequency: 60.0 kHz Station name: JJY (Fukushima, Fukuoka/Saga, Japan) Frequency: 40.0 kHz (Fukushima) / 60.0 kHz (Fukuoka/Saga) Station name: BPC (Shangqiu City, Henan Province, China) Frequency: 68.5 kHz
